Bonnell 902 Electric Motocross Bike

by Bonnell
SKU RB902-1
0 ( 0   )
<p>Earn%20[points_amount]%20when%20you%20buy%20this%20item.</p>
Sold out
Original price $0.00 - Original price $0.00
Original price
$0.00
$0.00 - $0.00
Current price $0.00

Fast & Free Shipping on Most Orders.
Low Price Guarantee – We’ll match or beat any authorized U.S. dealer’s price (conditions apply).
Financing Available – Flexible payment options (conditions apply).
Authorized U.S. Dealer for Every Brand We Sell.
Factory warranty coverage applies only to units originally sold by authorized U.S. dealers.
Have questions? Call or text 877-376-6380



Bonnell · 902 · Flagship

Bonnell's flagship. Built to push the limits.

The Bonnell 902 is not a mid-size compromise. It's a full-send, race-developed electric dirt bike built to compete with — and in some areas exceed — traditional 450-class machines. With over 60hp (46kW) and a massive 6.6 kWh swappable battery, it delivers brutal acceleration, sustained power, and real ride time without the drop-off smaller bikes suffer from.

This platform was built from a clean sheet. Custom motor, integrated custom gearbox, custom chassis, and the EBMX X42 controller working together to deliver one of the most advanced electric powertrains currently being developed. Fully tunable ride modes, IMU-based wheelie control, adjustable regen, and a programmable control lever round out a package that sits firmly in Stark Varg territory — but with a more modular, adaptable platform philosophy.



In development. The Bonnell 902 is still in development. Final specifications, components, and performance figures may change prior to release as testing and production are finalized. All electric dirt bikes sold by Lithium Powersports are intended for off-road use only, unless otherwise noted. The buyer is responsible for complying with local, state, and federal laws. Ride responsibly and wear proper safety gear.

Key Highlights

60+ HP (46kW) Peak Power

Full 450-class output. Custom high-torque motor paired with an integrated custom gearbox and EBMX X42 controller.

6.6 kWh Swappable Battery

The largest battery in the Bonnell lineup. Quick-swap for back-to-back track sessions. Race packs in development.

285mm Suspension Travel

Custom SIRRIS fork and R46 rear shock with more travel than the 805 — built for bigger hits and faster speeds.

Clean-Sheet Chassis

Hydroformed aluminum swingarm, 1440mm wheelbase, 21"/18" wheel setup. Purpose-built, not adapted.

EBMX X42 Controller

High-output race controller with fully tunable ride modes, traction control, IMU-based wheelie control, and adjustable regen.

Full App Tuning

Smartphone control over all ride parameters. Multi-mode display with lap timer. Programmable regen / clutch simulation lever.


Specifications

  • FrameFully custom chassis
  • SwingarmHydroformed aluminum
  • Wheelbase1440mm (56.5 in)
  • Wheel Setup21" front / 18" rear
  • Front ForkCustom SIRRIS
  • Rear ShockSIRRIS R46
  • Suspension Travel285mm front & rear
  • Peak Power46kW (60+ HP)
  • MotorCustom high-torque
  • GearboxIntegrated custom design
  • ControllerEBMX X42
  • Battery6.6 kWh swappable
  • Battery OptionsRace packs in development
  • Ride ModesFully tunable
  • Traction ControlYes
  • Regen BrakingAdjustable
  • Wheelie ControlIMU-based
  • Control LeverProgrammable regen / clutch sim
  • DisplayMulti-mode + lap timer
  • AppFull tuning via smartphone
